Gpib Maximum Cable Length

Ieee 488 gpib cable assemblies from l com include molded shielded inline reverse entry lszh and more.

Gpib maximum cable length. Additional information gpib supports up to a maximum total cable length of 20 m or 2 m times the number of devices whichever is less. Ieee 488 is a short range digital communications 8 bit parallel multi master interface bus specification developed by hewlett packard as hp ib hewlett packard interface bus it subsequently became the subject of several standards and is generically known as gpib general purpose interface bus. We offer one of the widest selections of gpib cable assemblies available anywhere. When you buy the gpib cable you can be sure of an automatic seamless compatibility between computers and the instruments throughout your system.

Keysight also offers a variety of gpib cables that provide easy and reliable connections. Ieee488 devices may be connected in either a star or linear fashion device to device. The gpib cable features 24 pin ieee 488 standard connectors designed to match the iee 488 specifications for digital communications. 783368 01 is 2 meters long.

The maximum cable length that can be used to connect devices to each other in a single system is 2 m x no. The gpib usb hs cable pn. Ieee488 has a maximum cable length of 20 meters or 2 meters per device which ever is less. Gpib cable manufacturers belden keithley single double shielded gpib cables ieee 488 to centronics cable adapter ines test and measurement normal cable lengths.

Keysight gpib cables are engineered for high reliability and durability even under harsh conditions. You can connect this cable to gpib compatible hardware such as controllers and test equipment. The gpib or ieee 488 bus is a very flexible system allowing data to flow between any of the instruments on the bus at a speed suitable for the slowest active instrument. System with a total of 2 devices 1 controller 1 gpib communication device 2 m x 2 devices 20 m so the maximum cable length of the whole system is 4 m.

Maximum cable length of 20 m maximum of 15 loads devices per bus e g one board and up to 14 instruments with at least two thirds of the devices powered on note. Of devices or 20 m whichever is shorter. Even though the maximum cable length between gpib devices is 4m you can still use an 8 meter cable to communicate with your devices.
